Specifications
- MFR:VALEO
- DIM 1:14mm ID Brush Ring
- FEATURE 1:100% New
- FEATURE 2:VSet controlled by Vehicle RVC system
- FEATURE 3:Field Rating 5 Amps
- FEATURE 4:Field Short Circuit Protection
- FEATURE 5:Stator or RVC Activated
- NOTE 1:Plug Code 346
- SPECS FOR:Valeo IR/IF Alternators
- SPECS:12 Volt, B-Circuit, High Side Drive Regulator, F-L Terminals, 13.8 Vset
USED ON
- Buick (2010-2019) ** Cadillac (2010-2012) ** Chevrolet (2010-2020) ** GMC (2010-2017) ** Saab (2011-2011)
Replaces
- Original Reference Number 1127-114RS, WG1776063, Valeo 2616783, 599386, 702152, 702153
LESTER NUMBERS
- 11399, 11453, 11456, 11459, 11485, 11486, 11487, 11560, 11650, 11652, 11654, 11696, 11697, 11734, 11828, 11831, 11832, 11932, 20202, 20505, 21019, 21037, 21215, 21221, 21227, 21284, 24099, 24107, 24109
UNIT NUMBERS
- GM 1202316, 1202332, 1204622, 13500314, 13500315, 13500316, 13500331, 13500576, 13500583, 13500586, 13501721, 13502581, 13502585, 13502588, 13502590, 13502591, 13502594, 13502988, 13502989, 13512756, 13512759, 13573791, 13577154, 13577411, 13579791, 13581891, 13586365, 13586366, 13586975, 13588289, 13588290, 13588298, 13588298, 13588301, 13588306, 13588308, 13588309, 13588312, 13588321, 13588324, 13588328, 13588329, 13597226, 13597227, 1359723, 13597233, 13597235, 13597244, 22962097, 23247389, 23247389, 23247389, 94741663, 95515962, 95515966, 95939943, 95939944; Opel 095515961, 1202119, 1202187, 1202188, 1202215, 1202219, 1202243, 1202319, 1202331, 1202336, 1202339, 1204437, 1204621, 1204622, 1204623, 1204642, 1204646, 1204647, 1204650, 1204651, 13500329, 13500332, 13500586, 13500856, 13502581, 13502593, 13577154, 13588304, 13802581, 19YY1715, AH1451; Original Reference Number 12090603, 12090641, 12090662, 130327014048, 130813193926, 200104153458, 200317202943, 200812194809, 200911040930, 201115062818, 201203202820, 210513200805, 210817010402, 220514102738, 220921160357, 230201091810, 230202221424, 230814082135, 4211, 430130133005, 430810125742, 431112093118, 59212829, 89215764, 9215392, 931043, 931238, 931331, 931542, AA7292, L 84 730; Polaris 13500316, 13588321; Saab 13-50-0331, 13-50-2590; Valeo 2605311A, 2605322A, 2605324A, 2605328, 2605328A, 2605854A, 2605870A, 2613307A, 2614154A, 2616735A, 2620305A, 2620362B, 2650745A, 440621, 440637, FG12S012, FG12S014, FG12S015, FG12S017, FG12S029, FG12S030, FG12S031, FG12S032, FG12S043, FG12S044, FG12S047, FG12S048, FG12S053, FG12S054, FG12S055, FG12S058, FG12S064, FG12S065, FG12S070, FG12S071, FG12S072, FG12S073, FG12S074, FG12S075, FG12S076, FG12S077, FG12S078, FG12S079, FG12S080, FG12S081, FG15S019, FG15S026, FG15S027, FG15S032, FG15S083, FG15S084, FG15S095, FG15S097, FG15S100, FG15S104, FGN12S064, FGN12S065, FGN12S070, FGN12S071, FGN12S072, FGN12S073, FGN12S074, FGN12S075, FGN12S076, FGN12S077, FGN12S078, FGN12S079, FGN12S080, FGN12S081, FGN12S096, FGN12S104, FGN12S106, FGN12S115, FGN12S116, FGN12S116, FGN12S118, FGN12S119, FGN12S120, FGN12S121, FGN15S097, FGN15S104, FGN15S139, TG12C036, TG12C052, TG12C053, TG12C054, TG12C055, TG12C056, TG12C065, TG12C066, TG12C067, TG12C069, TG12C070, TG12C071, TG12C072, TG12C073, TG12C074, TG12C075, TG12C076, TG12C105, TG12C131, TG12C137, TG12C138, TG12C143, TG12C144, TG12C154, TG12C155, TG12C172, TG12C172SP, TG12C173, TG12C173SP, TG12C174, TG12C175, TG12C176, TG12C176, TG12C177, TG12C178, TG12C179, TG12C180, TG12C181, TG12C182, TG12C183, TG12C184, TG12C185, TG12C186, TG12C187, TG12C188, TG12C189, TG12C190, TG12C191, TG12C192, TG12C193, TG12C194, TG12C227, TG12C282, TG12C283, TG12C284, TG12C285, TG12C286, TG12C287, TG12C288, TG12C290, TG12C291, TG12C292, TG12C293, TG12C294, TG12C295, TG12C296, TG12C297, TG12C298, TG12C299, TG12S032, TG9S113; Vauxhall 13502582, 13502987, 13505392, 13581893, 13588296, 13588307, 13588330, 95515961, 95515968, 95515971, 95520018
