Specifications
- DIM 1:7.1mm ID x 14.3mm OD
- NOTE 1:28-1856 is used on most CS130D rotors w/ 11-blade or 16-blade black-color plastic fan.
- NOTE 2:For late style CS130D rotors with 16-blade tan-color plastic fan use 28-1860 slip ring.
- NOTE 3:28-1856 is similar to 28-1856-2 except 28-1856-2 has the lead insulation pre-stripped for installation.
- SPECS FOR:Delco CS130D Series IR/IF Alternators
USED ON
- Acura (1997-1999) ** Buick (1999-2001) ** Chevrolet (1997-2005) ** Chevrolet - Europe (2005-2013) ** Crusader (1999-2004) ** Daewoo (1999-2002) ** Daewoo - Europe (1997-2005) ** GMC (1998-2005) ** Honda (1998-2002) ** Hyster (2001-2006) ** Isuzu (1998-2001) ** Marine Power (1997-2008) ** Mercruiser (1998-2002) ** Oldsmobile (1997-2003) ** Opel - Europe (1992-2004) ** Pleasurecraft (2001-2004) ** Pontiac (1998-2003) ** Porsche (2003-2006) ** Vauxhall - Europe (1988-2001) ** Volkswagen (2002-2004)
Replaces
- Delco 10475750, 10475751
LESTER NUMBERS
- 11059, 11060, 23999, 24001, 8220, 8224-11, 8230-7, 8233-7, 8234-5, 8236, 8239, 8242-5, 8243-5, 8246-5, 8249-7, 8277, 8281, 8286, 8460, 8463, 8466, 8467, 8468, 8469, 8495-3, 8496-9
UNIT NUMBERS
- Acura 06311-P8C-505RM, 31100-P8A-A01, 31100-P8A-A02; Audi, Volkswagen 07C-903-021K, 07D-903-021, 07D-903-021X; Daewoo 219170, 219232, 96206871, 96341300; Delco 10447094, 10447096, 10463963, 10464070, 10464090, 10464097, 10464396, 10464402, 10464407, 10464412, 10464413, 10464414, 10464415, 10464416, 10464417, 10464420, 10464425, 10464429, 10464449, 10464480, 10464485, 10464487, 10464488, 10464492, 10475748, 10479384, 10479923, 10480228, 10480292, 10480298, 10480299, 10480308, 10480317, 10480330, 10480331, 10480342, 10480343, 10480344, 10480346, 10480348, 10480352, 10480354, 10480377, 10480453, 10480480, 10480485, 10480500, 10480546, 10484420, 10486544, 10486582, 10486588, 10486594, 10488937, 10492396, 15087022, 15087024, 15744913, 15768315, 19020601, 19020606, 19020608, 19020614, 19020615, 19020616, 19020617, 19052295, 19244752, 19244792, 19244796, 219292, 25744163, 25744165A, 3493923; Fiat 71723409, 71723410; GM 10464070, 10464090, 10464097, 10464396, 10464407, 10464415, 10464420, 10464425, 10464429, 10464449, 10464485, 10464492, 19244743, 25744165, 28-5612, 96206871; Honda 06311-P8C-505RM, 31100-P8A-A01, 31100-P8A-A02, 31100-P8C-A02, 31100-P8C-A02RM; Hyster 1469599; Indmar 575010, 575011; Isuzu 8104799230; Korea Delphi Automotive Systems Corparat 96289030, 96567255; Lancia 60667066; Marine Power 4711210, 471200, 471201, 471210; Mercury Marine 862031, 862031T, 862031T1; Opel 10480409, 1204145, 3493823, 3493824, 6204000, 6204002, 6204151, 6204196, 90356897, 90443929, 93175788, 93175815, 93175963, 93181383, 9512800; Original Reference Number 10480228A, ADG01179C, QY19J7-923, QY2367, QY30H7; Pleasurecraft Marine RA097007, RA097007A, RA097007B, RA097007L; Porsche 948-603-015-01, 948-603-015-02, 948-603-015-03; Prestolite 20115012TBA, 20115014TBA, 20115016TBA; Vauxhall R1530052
