Specifications
SPECS: 9-T, CW, 10-SPL
SPECS FOR: Bosch DD Starters
DIM 1: 12mm ID, 25.5mm Gear OD, 64mm L
NOTE 1: Splines flush to end of drive.
LESTER NUMBERS
16543, 16954, 17043, 30453, 30475, 30917, 30918, 32336, 32766, 33124
Replaces
Audi, Volkswagen 073-911-335, Bosch 1 006 209 469, 1 006 209 470, 1 006 209 473, Fiat 9936671, Mercedes-Benz 000-151-87-13, 000-151-90-13, Volvo 1367374
UNIT NUMBERS
Audi, Volkswagen 073-911-023, 073-911-023-X, 073-911-023X; Bosch 0 001 311 146, 0 001 311 147, 0 001 314 005, 0 001 314 026, 0 001 314 027, 0 001 314 028, 0 001 314 029, 0 001 314 030, 0 001 314 033, 0 001 314 034, 0 001 314 035, 0 001 314 036, 0 001 314 037, 0 001 314 038, 0 001 314 041; DAF 1516718R; Fiat 43924610, 5997309; Lancia 4392461, 43924610, 5997309; Letrika (Iskra) Tech. AZE2521, AZE2545, AZJ3182; Letrika Old IS 9330; Magneton 9-141-385, 9-141-404; Marelli 063223332010, 943251223010, 944280108900; Mercedes-Benz 002 151 93 01 80, 002-151-43-01, 002-151-93-01, 002-151-96-01, 002-151-97-01, 002-151-98-01, 002151930180, 003-151-00-01, 003-151-19-01, 003-151-38-01, 003-151-99-01, A0021514301, A0021519301, A002151930180, A0021519701, A0021519801, A0031513801, A0031519901; Prestolite 20500729; PSA Peugeot Citroen 91040098, 9104009880; Seat 0004394261; Talbot 9104009880; Valeo 463856; Volvo 1346707, 1346707-0, 1346707-1, 204284, 5001599, 5001599-0, 5001599-9, 5001613, 5002046-0, 5003617, 5003617-0, 5003617-7
Aftermarket Starter Drive 54-9147 Product Overview
Aftermarket Starter Drive 54-9147 is an aftermarket starter drive intended for compatible starter repair, rebuilding, and maintenance applications. It is designed for professional rebuilders, technicians, repair shops, and customers who need a dependable replacement for a worn, damaged, corroded, or missing component. Before ordering, confirm the product name, part number 54-9147, measurements, mounting style, connector configuration, original equipment references, and application information.
Product Specifications and Application Details
The original listing provides these product-specific details: Specifications SPECS: 9-T, CW, 10-SPL SPECS FOR: Bosch DD Starters DIM 1: 12mm ID, 25.5mm Gear OD, 64mm L NOTE 1: Splines flush to end of drive. LESTER NUMBERS 16543, 16954, 17043, 30453, 30475, 30917, 30918, 32336, 32766, 33124 Replaces Audi, Volkswagen 073-911-335, Bosch 1 006 209 469, 1 006 209 470, 1 006 209 473, Fiat 9936671, Mercedes-Benz 000-151-87-13, 000-151-90-13, Volvo 1367374 UNIT NUMBERS Audi, Volkswagen 073-911-023, 073-911-023-X, 073-911-023X; Bosch 0 001 311 146, 0 001 311 147, 0 001 314 005, 0 001 314 026, 0 001 314 027, 0 001 314 028, 0 001 314 029, 0 001 314 030, 0 001 314 033, 0 001 314 034, 0 001 314 035, 0 001 314 036, 0 001 314 037, 0 001 314 038, 0 001 314 041; DAF 1516718R; Fiat 43924610, 5997309; Lancia 4392461, 43924610, 5997309; Letrika (Iskra) Tech. AZE2521, AZE2545, AZJ3182; Letrika Old IS 9330; Magneton. Use this information together with the product photographs, dimensions, cross-reference numbers, and application notes when confirming the correct replacement.
Key Features and Benefits
- Product-specific aftermarket replacement for compatible starter applications
- Part-number-focused identification for easier comparison and ordering
- Suitable for professional repair, rebuilding, inspection, and maintenance work
- Designed to support dependable fit, operation, and long-term service performance
- Useful for matching original equipment numbers and common cross-reference numbers
Compatibility and Fitment Guidance
Fitment can vary by vehicle model, starter or alternator design, production date, manufacturer, connector style, mounting configuration, and original equipment number. Compare the listed part number, product photos, dimensions, Lester numbers, unit numbers, and replacement references with the original component. Contact RCAutoElectric when additional compatibility confirmation is required.
Professional Installation Notes
Inspect the complete assembly and related components before installation. Professional installation or rebuilding service is recommended whenever specialized tools, electrical testing, soldering, pressing, torque specifications, or technical adjustments are required.
Explore Related RCAutoElectric Categories
Starters | Starter Parts | Starter Rebuild Kits | Alternators | Alternator Parts | Alternator Rebuild Kits
Read More
Frequently Asked Questions
How do I confirm this part is compatible? +
Compare 54-9147, dimensions, cross-reference numbers, mounting details, application notes, and product images with the original component before ordering.
Is this an OEM part or an aftermarket replacement? +
This listing is for an aftermarket starter drive unless the original title or description specifically states that the item is OEM.
What should I verify before ordering? +
Check the original equipment number, unit number, measurements, connector style, mounting design, rotation or polarity when applicable, and all fitment details in the listing.
Is professional installation recommended? +
Professional installation or rebuilding service is recommended when the job requires special tools, electrical testing, soldering, pressing, torque settings, or technical adjustments.
