Specifications
SPECS: 9-T, CW, 10-SPL
SPECS FOR: Bosch 362 Series DD Starters
DIM 1: 14.3mm ID, 35mm Gear OD, 74mm L
LESTER NUMBERS
17093, 18031, 18461, 30036, 30828, 31858, 31859
Replaces
Alfa Romeo 9983629, Bosch 2 006 209 470, 2 006 209 483, 9 001 451 343, Fiat 79026090, 9936730, 9937949, 9956676, 9983629, KHD 998 3629
UNIT NUMBERS
Audi, Volkswagen 0004448694; Bosch 0 001 362 039, 0 001 362 062, 0 001 362 073, 0 001 362 102, 0 001 362 105, 0 001 362 322, 0 001 362 323, 0 001 363 101, 0 001 363 111, 0 001 363 122, 0 001 363 128, 0 001 363 130; DAF 1516715R, 1516722R, 1516792R; Fiat 0004448694, 4412894, 4448694, 46231640, 4691200, 4706931, 4711699, 4713807, 4728682, 4741699, 4744841, 4819723, 7564668, 77028560, 77050561, 77080560, 77080561, 77515430, 929162; Iveco 106055, 1363111, 4448694, 4719664, 4728682, 4744811, 4744841, 4781237, 4856055, 500333269, 504038038, 504072485, 504116555, 60196656; KHD 04691200, 04744841; Lancia 4172113, 4412894, 4448694, 4710224, 4713807, 4728682, 4741699, 4759929, 77515430; Letrika (Iskra) 11.130.203, 11.130.216, 11.131.603; Letrika (Iskra) Tech. AZE6531, AZJ3137, AZJ3156, AZJ3538, AZJ3542; Lucas LRT00136; Magneton 9-124-320, 9-142-840, 9-144-744, 9-144-745; Marelli 063217126010, 063217148010, 063217154010, 063217226010, 063217410010, 30180304, 944280110800; New Holland 500333269; Prestolite 20500839, 20500850, 35259940; Seat 0004448694; Unic 004691200; Valeo 436075
Aftermarket Starter Drive 54-9117 Product Overview
Aftermarket Starter Drive 54-9117 is an aftermarket starter drive intended for compatible starter repair, rebuilding, and maintenance applications. It is designed for professional rebuilders, technicians, repair shops, and customers who need a dependable replacement for a worn, damaged, corroded, or missing component. Before ordering, confirm the product name, part number 54-9117, measurements, mounting style, connector configuration, original equipment references, and application information.
Product Specifications and Application Details
The original listing provides these product-specific details: Specifications SPECS: 9-T, CW, 10-SPL SPECS FOR: Bosch 362 Series DD Starters DIM 1: 14.3mm ID, 35mm Gear OD, 74mm L LESTER NUMBERS 17093, 18031, 18461, 30036, 30828, 31858, 31859 Replaces Alfa Romeo 9983629, Bosch 2 006 209 470, 2 006 209 483, 9 001 451 343, Fiat 79026090, 9936730, 9937949, 9956676, 9983629, KHD 998 3629 UNIT NUMBERS Audi, Volkswagen 0004448694; Bosch 0 001 362 039, 0 001 362 062, 0 001 362 073, 0 001 362 102, 0 001 362 105, 0 001 362 322, 0 001 362 323, 0 001 363 101, 0 001 363 111, 0 001 363 122, 0 001 363 128, 0 001 363 130; DAF 1516715R, 1516722R, 1516792R; Fiat 0004448694, 4412894, 4448694, 46231640, 4691200, 4706931, 4711699, 4713807, 4728682, 4741699, 4744841, 4819723, 7564668, 77028560, 77050561, 77080560, 77080561, 77515430, 929162; Iveco 106055, 1363111, 4448694, 4719664, 4728682, 4744811, 4744841, 4781237. Use this information together with the product photographs, dimensions, cross-reference numbers, and application notes when confirming the correct replacement.
Key Features and Benefits
- Product-specific aftermarket replacement for compatible starter applications
- Part-number-focused identification for easier comparison and ordering
- Suitable for professional repair, rebuilding, inspection, and maintenance work
- Designed to support dependable fit, operation, and long-term service performance
- Useful for matching original equipment numbers and common cross-reference numbers
Compatibility and Fitment Guidance
Fitment can vary by vehicle model, starter or alternator design, production date, manufacturer, connector style, mounting configuration, and original equipment number. Compare the listed part number, product photos, dimensions, Lester numbers, unit numbers, and replacement references with the original component. Contact RCAutoElectric when additional compatibility confirmation is required.
Professional Installation Notes
Inspect the complete assembly and related components before installation. Professional installation or rebuilding service is recommended whenever specialized tools, electrical testing, soldering, pressing, torque specifications, or technical adjustments are required.
Explore Related RCAutoElectric Categories
Starters | Starter Parts | Starter Rebuild Kits | Alternators | Alternator Parts | Alternator Rebuild Kits
Read More
Frequently Asked Questions
How do I confirm this part is compatible? +
Compare 54-9117, dimensions, cross-reference numbers, mounting details, application notes, and product images with the original component before ordering.
Is this an OEM part or an aftermarket replacement? +
This listing is for an aftermarket starter drive unless the original title or description specifically states that the item is OEM.
What should I verify before ordering? +
Check the original equipment number, unit number, measurements, connector style, mounting design, rotation or polarity when applicable, and all fitment details in the listing.
Is professional installation recommended? +
Professional installation or rebuilding service is recommended when the job requires special tools, electrical testing, soldering, pressing, torque settings, or technical adjustments.
Where can I find related repair parts? +
Use the internal links in the SEO section to browse related starters, starter parts, starter rebuild kits, alternators, alternator parts, and alternator rebuild kits.
