Specifications
- MFR:DELCO
- FEATURE 1:100% New Transpo Heavy Duty ASVR Design
- FEATURE 2:OE compliant functions & performance: current limiting, thermal shutdown, load dump protection, shorted field & lamp circuit protection
- FEATURE 3:Welded construction - no solder joints for hi-temperature reliability & increased field life
- NOTE 1:B+ connection made at rectifier lead-frame (not under B+ stud spacer)
- SPECS FOR:Delco AD230, AD237, AD244 Series IR/IF Alternators
- SPECS:12 Volt, B-Circuit, P-L-F-S Terminals, 14.8 Vset, 2.5 sec. LRC
USED ON
- Buick (2006-2006) ** Cadillac (2002-2002) ** Chevrolet (1999-2010) ** GMC (1999-2006) ** Isuzu (2003-2006) ** Oldsmobile (1999-2002) ** Saab (2005-2006)
Replaces
- Delco 10458200, 10483643, 10486311, 10494747, 19051915, 19053013, 19053730, Original Reference Number 3643, 6311
LESTER NUMBERS
- 8237, 8241, 8247, 8273, 8290, 8292-253
UNIT NUMBERS
- Delco 10311493, 10464395, 10464405, 10464405, 10464443, 10464443, 10464452, 10464453, 10464455, 10464456, 10464476, 10480234, 10480234, 10480285, 10480326, 10480327, 10480341, 10480383, 10480390, 10480390, 10480476, 15200109, 15226003, 15750871, 15754097, 15754097A, 15754097M, 15754097W, 15768829, 15768830, 18000002, 19244728, 19244731, 19244745, 19244746, 22781130; GM 10464395, 10464405, 10464443, 10464451, 10464453, 10464455, 10464456, 10464469, 15263859, 19151921, 19244731, 19244738, 19244751; Isuzu 8104644760, 8152260030; Original Reference Number 10480234W, 10480326M, 10480326M, 10480341W; Saab 15-22-6003
