Specifications
- DIM 1:21mm Belt x 58mm Rib OD x 17mm Bore, M14 Threads
- DIM 2:9mm from hub to center of 1st groove
- DIM A (MM):17
- DIM B (MM):55
- DIM C (MM):43
- DIM D (MM):9
- FEATURE 1:100% New
- GROOVES:6
- SPECS FOR:Denso ER/IF Alternators
- SPECS:6-Groove Clutch Pulley
- TYPE:OAP
USED ON
- Chrysler (2004-2007) ** Dodge (2004-2007)
Replaces
- Chrysler 04861506AD, 04861506AG, Denso 021010-1440, 021040-1440, INA Bearing Co 535 0208 10, Original Reference Number 243C2
LESTER NUMBERS
- 11063, 13871
UNIT NUMBERS
- Chrysler 04868431AF, 04868431AG, 04868760AE, 04868760AF, 04868760AF1, 04868760AH, 4868431AF, 4868431AG, 4868760AD, 4868760AE, 4868760AF, 4868760AH; Denso 421000-0222, 421000-0223, 421000-0225, 421000-0300, 421000-0301, 421000-0302, 421000-0303, 421000-0304
