Specifications
SPECS:12 Volt
SPECS FOR:Mitsubishi 1.0, 1.2, 1.4kW PMGR Starters
Dim 1:121mm OAL
Dim 2:11-Splines
Dim 3:10mm Shaft OD Front Bearing
Dim 4:8mm Shaft OD Rear Bearing
FEATURE 1:100% New
FEATURE 2:Precision machined shaft with ground bearing surfaces
FEATURE 3:Heat treated splines & bearing surfaces
FEATURE 4:Commutator with thick copper segments & stake welded hairpins
FEATURE 5:Banded hairpins at commutator
FEATURE 6:100% tested for balance, grounds & shorts
LESTER NUMBERS
16874, 16888, 16900, 16931, 16933, 16939, 16998, 17131, 17132, 17142, 17146, 17151, 17161, 17166, 17185, 17217, 17221, 17246, 18095, 30322, 31156, 31338
Replaces
Hyundai 36150-32500, Mazda F214-18-X60, N326-18-X60, Mitsubishi M106X06971, M106X50171, M106X50471, Mitsubishi Motors MD611204, MD618451, Nissan, Infiniti 23310-42L70, 23310-65Y10, Subaru 23310-AA000, Suzuki 31311-86031
UNIT NUMBERS
Chrysler MD099667, MD136933, MD162839, MD162840, MD162842, MD162843, MD309471, R099667M; Ford E92Z-11002-A, F02Z-11002-B, F12Z-11002-A, F12Z-11002-ARM; GM 19135378, 30005925, 96058457; Hyundai 00228-Y0220, 00228-Y9100, 36100-22100, 36100-32510, 36100-32520, 36100-32530, 36100-35010, 36100-35020, 36100-35030, 36100-35040, 36100-35050, 3610035050AT; Mando M42373, MG112022, MP112041; Marelli 063226845010, 063522617010, 063522624010, 944280523190, 944280528050, 944280528100, 944280528110, 944280528120; Mazda AM15-18-400, AM15-18-400A, F214-18-400, F214-18-400A, F214-18-400B, F214-18-400C, F214-18-400R, F214-18-400R00, F225-18-400A, F271-18-400, F271-18-400A, F271-18-400B, F2D4-18-400, F2D4-18-400A, FE1H-18-400, FE1H-18-400R00, JE15-18-400, JE15-18-400A, JE15-18-400B, JE15-18-400R, N326-18-400, N326-18-400A, N326-18-400B; Mitsubishi M001Q71281, M001T70281, M001T70281ZC, M001T70283, M001T70283ZC, M001T70381, M001T70481, M001T70482, M001T70483, M001T70485, M001T70685, M001T70687, M001T70781, M001T70781A, M001T70885, M001T70981, M001T70981A, M001T70982, M001T70982A, M001T70985, M001T70985A, M001T71081, M001T71281, M001T71281A, M001T71281B, M001T71382, M001T71388, M001T71388ZC, M001T71481, M001T71481A, M001T71581, M001T71681, M001T71881, M001T71881A, M001T72081, M001T72085, M001T72086, M001T72086A, M001T72087, M001T72087A, M001T72088, M001T72182, M001T72281, M001T72481, M001T72483, M001T72581, M001T72583, M001T72681, M001T72781, M001T72781A, M001T72781B, M001T72985, M001T73281, M001T73283, M001T73381, M001T73383, M001T79081, M002T72085; Mitsubishi Motors M099667D, MD099667, MD136933, MD145183, MD162839, MD162840, MD162842, MD162843, MD309471; Nissan, Infiniti 23300-01Y10, 23300-01Y10R, 23300-01Y11, 23300-20P10, 23300-20R10, 23300-20R11, 23300-20R91, 23300-20R91R, 23300-22P71, 23300-30F10, 23300-30F11, 23300-30F11RE, 23300-30R12, 23300-53F11, 23300-53F11R, 23300-57M70, 23300-57M90, 23300-57M90R, 23300-63J10, 23300-63J11, 23300-65Y10, 23300-70J00, 23300-72F10, 23300-77A11, 23300-84A17, 23300-84A17R, 23300-84A18, 23300-D0511, 23300-D0512, 23300-D0513, 23300-D0514; Subaru 23300-AA040; Suzuki 31100-60A20, 31100-60A21, 31100-86030, 31100-86031, 31100-86032, 31100-860D2, 31100-860D2-REM; Valeo 455581, 455583, 455884, 455915, TM000A03801, TM000A04001, TM000A04101, TM000A04201, TM000A04301, TM000A04801, TM000A05101, TM000A24601
Read More
