Specifications
- FEATURE 1:100% New
- NOTE 1:L(RC) terminal is computer RVC(PWM) connection, not Lamp
- NOTE 2:Regulator damage if tested as Lamp connection
- SPECS FOR:Delco IR/IF Alternators
- SPECS:12 Volt, B-Circuit, L(RC)- F(FR) Terminals, 13.8 Default Vset
USED ON
- Chevrolet (2012-2020)
Replaces
- Delco 13582947, 3C1112, 4G1403, LRC25D, Original Reference Number 222725K, GNR-D022
LESTER NUMBERS
- 20079, 20096, 20980, 21512, 21513, 21514
UNIT NUMBERS
- Delco 13500582, 13501719, 13502583, 13579663, 13579666, 13579668, 13579677, 13580078; GM 1202236, 1204643, 1204654, 13500577, 13500582, 13501719, 13502583, 13502595, 13579663, 13579666, 13579667, 13579668, 13580078, 13595629; Opel 1200262, 1202120, 1202262, 1202284, 1204180, 13579667, 13580078, 4818330, 4819446; Vauxhall 13501719, 13580078
